Unleash Ultimate Speed
Features:
- Exceptional Power and Speed: The motor delivers high power output and supports high RPM, making it an ideal choice for high-speed applications.
- Optimized ESC Compatibility: Designed for seamless integration with the EzRun MAX5 HV Plus G2 ESC, enabling higher speeds and increased power output when paired.
- Effective Heat Dissipation: The motor features a grooved design for effective heat dissipation, reducing temperature increases and prolonging high-power, high-torque output.
- Durable Construction: Built with premium materials, including CNC-machined aluminum housing, top-tier bearings, ultra-thin silicon steel laminations, high-temperature-resistant oxygen-free copper wires, carbon fiber-wrapped explosion-resistant rotor, and high-strength alloy output shaft. These features ensure sustained high performance over time.
Specifications:
- KV Value: 2400KV
- LiPo Cells: 6-8S
- No-load Current: 16A
- Outer Diameter/Length: 56mm(2.2in)/90.5mm(3.56in)
- Shaft diameter/Exposed shaft length: 8mm(0.315in)/30mm(1.18in)
- Bearing Size(mm): Front: D22*D8*T7 Rear: D19*D8*T6
- Pole: 4
- Weight: 885g
- Application: 1/7 and 1/8 vehicles for Extreme Speed
